Description
Features
- Intrinsically safe – the instrument does not contain radioactive sources and does not require any license to use
- Efficient detection – fast start-up, detection, and analysis time; results in 5 seconds with fast recovery
- Various types of libraries – rich standard samples; database can reach nearly 100 types
- High sensitivity – pg level for explosives, ng level for drugs
- Rich data interface – export detection data via USB; supports WiFi/Bluetooth/Ethernet for connection to phones, tablets, or PCs
- Can be used as a detection terminal to build a big data visualization platform and enable remote monitoring
Parameters
| Content | Technical Indicators |
|---|---|
| Dimensions | 348 × 322 × 355 mm |
| Weight | 8.24 kg |
| Working Voltage and Mode | 15V or lithium battery powered |
| Rated Power | 120W |
| Communication Interface | Ethernet, USB, WIFI |
| Operation Method | Touch screen |
| Sampling Method | Wipe or inhale |
| Sensitivity | Drugs: ng level; Explosives: pg level |
| Types of Drugs that Can Be Detected | Meth, cocaine, heroin, K powder, opium, morphine, marijuana, pethidine, methadone, amphetamines, ecstasy, caffeine, moxa, codeine (expandable) |
| Detectable Types of Explosives | TNT, ammonium nitrate, RDX, Taian, Octogen, C4, Tetryl, TATP, DNT, nitroglycerin, ammonium antimony, picric acid, nitroguanidine (expandable) |
| Start Time | ≤ 30s |
| Analysis Time | ≤ 6s |
| Overload Recovery Time | ≤ 1 min (with self-cleaning function) |
| Preheat Time | ≤ 18 min |
| Display | 10.1-inch (1920×1200) LCD touch screen |
| Alarm Mode | Sound, color, text display |
| Data Storage | 64G storage; stores ≥ 100,000 records; supports backup via network port, USB, etc. |
| Operating Software | Chinese operating software; customizable |
| Working Environment Humidity | ≤ 93% |
| Storage Temperature | -40℃ ~ 60℃ |
| Protection Level | IP52 |
| Radiation Safety | No radioactive source |
Application Area
Security inspection in civil fields such as airports, subways, train stations, ports, industrial parks, and large public events. Used by customs, border defense, armed police, and other national government agencies and military departments. Also suitable for physical evidence inspection by public security, courts, and national law enforcement agencies, as well as experimental research on poisons and explosives in scientific research universities and research institutes.
