Solafact 6010

Solafact 6010

Solafact 6010

Product Introduction

SOLAFACT 6010 is a portable biological aerosol monitor developed based on Ultraviolet Laser-Induced Fluorescence technology. Its primary function is to monitor and provide early warning for biological aerosol particles in the ambient air. The principle behind this technology is that when aerosol particles pass through a strong ultraviolet light beam, they get excited, resulting in the emission of biological fluorescence and diffraction scattering. By employing a high-stability gas sheath flow structure, a highly precise optical detection system, and a sensitive photodetector, it can convert and detect the photonic signals, allowing for the quantification of the aerosol particles being tested. Additionally, by using a particle size distribution algorithm, it can further distinguish between the biological and non-biological properties of the particles.

Description

Features
  • High analysis sensitivity with 405 nm semiconductor laser for single-photon excitation and particle counting
  • Low false alarm rate for rapid discrimination of biological and non-biological particles
  • Compact, lightweight, and easy to maintain with extended operational lifespan
  • Fast response time with results delivered within 30 seconds
  • Strong resistance to interference from smoke, exhaust, NO₂, pollen, dust, and other particulates
Technical Indicators
Name Technical Parameters
Particle Types and Particle Size Range Capable of capturing bacteria, spores, viruses, and toxins in the size range of 0.5μm to 10μm
Particle Size Measurement Error Not exceeding ±30%
Lower Limit of Detection for Biological Aerosol Monitoring ≤100 ACPLA
Self-Cleaning Time ≤3 min
Alarm Time ≤30 s
Operating Temperature -20℃ to 50℃
Storage Temperature -40℃ to 60℃
Application Area

It finds extensive application in areas related to inspection and quarantine at ports, customs, and airports, as well as in aseptic cleanrooms for quarantine purposes. It is also used in ensuring security for crucial departments, safeguarding major events, providing early warning for bioterrorism threats, and preemptively detecting biological agents.
