Description
Features
- Rapid response, detection within 10 seconds
- Quick zeroing, rapid recovery for the next detection after detecting high-concentration chemicals, no need for flushing or backwashing.
- Capable of detecting mixtures.
- Small size, light weight, easy to carry, one-button activation, no setup and calibration required, simple operation, easy to use
- It can detect solid, liquid and gas three-phase substances, covering about 140 chemicals including phosphorus, sulfur, arsenic, nitrogen, hydrogen and oxygen, and flammable gases.
- Wide detection range
- High sensitivity
- Efficient detection
- Easy to carry and easy to use
- Intrinsic safety
- Data storage function
- Ultra-high detection sensitivity, phosphorus, sulfur, and arsenic substances can be detected at ppb level.
- Built-in data storage chip stores historical detection data, and the data supports user acquisition
- The instrument does not contain radioactive sources and does not require approval from the environmental protection department
Parameters
| Detection principle | full-spectrum flame photometry |
| Host size | 390mm×110mm×142mm |
| Host weight | 2 kg (excluding hydrogen tank and battery) |
| Power supply | 18650 lithium battery (4 cells) |
| Types and Forms of Detection | Phosphorus-based (G, V) toxins: Examples include Tabun, Sarin, Soman, VX, Cyclosarin, and others. Sulfur-based (HD, HL) toxins: Examples include Mustard gas (HD), Organic sulfur agents, Sulfur dioxide, Nitrogen sulfide, and Sulfur monochloride. Arsenic-based (L, SA) toxins: Examples include Lewisite (L), Arsenic, Diphenylchloroarsine, Arsenic trichloride, Ethyldichloroarsine, and Benzene arsenic dichloride. Nitrogen, Hydrogen, and Oxygen-based (HN, AC) toxins: Examples include Nitrogen mustard (HN), Hydrogen cyanide, Hydrochloric acid, Phosgene oxime, Acrylonitrile, and Triethanolamine. Flammable gases: This category may include various flammable gases, but “CH” typically represents the chemical formula for methane, a common flammable gas. |
| Detection of Substance Forms | solid, liquid, gas |
| Hydrogen Cylinder Usage Time | 12 hours |
| Sensitivity | Phosphorus 2ppb; sulfur 70ppb; arsenic 150ppb; nitrogen, hydrogen and oxygen 3ppm |
| Continuous working time | 20℃: 11 hours 50℃: 8 hours 0℃: 4 hours and 30 minutes -10℃: 2 hours and 45 minutes |
| Startup time | 0℃ ~35℃: 2 minutes 35℃ ~50℃: 4 minutes -10℃ ~0℃: 15 minutes |
| Response time | 2-10 seconds |
| Operating temperature | -10℃ ~50℃ |
| Storage temperature | -39℃ ~71℃ |
| Operating altitude | 0 to 3000 meters |
| Communication method | RS485 |
Application Area
It can be widely used in national security, military investigation, anti-terrorism chemical attacks, chemical accident rescue, industrial production, environmental monitoring, fire protection and other fields.
