Description
Features
- Using high-performance and long-life Stirling-cooled MCT detector, the detection range reaches ppm-percentage
- Equipped with a precision optical scanning pan/tilt, horizontal 360° scanning, pitch ±90°, monitoring radius greater than 3 km
- Has a high-speed and stable optical-mechanical hardware system that can achieve 4 cm⁻¹ / 16 frames/second fast scanning
- Meets the requirements for detection and identification of hundreds of industrial compounds (TICs) and chemical warfare agents (CWAs)
- It has multiple mixture detection capabilities and can detect and identify at least 6 mixtures of gas substances
- No external excitation light source is required, detection and identification can also be performed in complex dark environment backgrounds
- Optimized algorithms for instrument self-inspection, self-calibration, path interference diagnosis, water vapor compensation, etc.
- Equipped with a multi-functional monitoring terminal to meet user needs such as daily environmental monitoring, threat identification, sound and light alarm, information storage and playback, etc., and the functions support customization
- Product functions support customization, the system can be loaded on mobile carriers such as vehicles, ships, helicopters, drones, etc., and perform tasks on the move
- Exquisite structural design, simple installation and convenient operation
- Using Fourier transform infrared spectroscopy detection technology, long-distance non-contact sampling
- No consumables, no radioactive sources, no secondary pollution, and extremely low maintenance costs
Technical Indicators
| Content | Technical Specifications | |
|---|---|---|
| Spectral Range | 600 cm⁻¹ ~ 1500 cm⁻¹ | |
| Dimensions | 396 mm (L) × 360 mm (W) × 382 mm (H) | |
| Host Weight | < 30 kg, Shock Absorbing Bracket < 10 kg | |
| Spectral Resolution | Regular 4 cm⁻¹, Maximum 1 cm⁻¹ | |
| Detector | Domestic MCT mercury cadmium telluride detector (lifetime > 12000 h) | |
| Beam Splitter | Domestic moisture-proof ZnSe beam splitter | |
| Detection Distance | > 3 km | |
| Monitoring Scope | Pan 360°, Pitch ±90° | |
| Calibrate Blackbody | High-performance high and low temperature blackbody (-30°C ~ 150°C) | |
| Test Type | More than 430 measurable substances | |
| Instrument Detection Limit | 50 ppm·m (2°C temperature difference) @ ammonia or ethylene | |
| Spectral Acquisition Rate | Normally 10 times/second | |
| Telescope | Military-grade 2× off-axis telescope | |
| Working Temperature | -20°C ~ 55°C | |
| Storage Temperature | -40°C ~ 65°C | |
| Protection Level | IP65 | |
| Mixture Testing | Real-time online early warning monitoring of more than 3 mixtures | |
| Anti-vibration and Impact Characteristics | Meets GJB150A-2009 crawler vehicle vibration program, impact program, environmental operation early warning monitoring, heavy oil UAV anti-vibration test for long-distance remote sensing | |
Application Area
Passive Fourier infrared remote sensing analyzers can be widely used in national defense, emergency, anti-terrorism, environmental monitoring, fire protection, petroleum, chemical industry parks, emergency detection of sudden chemical accidents, large-scale event security, long-distance detection of gas leaks, and long-distance air pollution analysis, industrial production pollutant emission monitoring and other fields.
