Description
Features
- Equipped with a multi-functional monitoring terminal to meet user needs such as daily environmental monitoring, threat identification, sound and light alarm, information storage and playback
- Equipped with various communication interfaces such as network port, 5G, WiFi, etc., multiple devices can work together to meet various application scenarios
- Product functions support customization to better serve users
- Using high-performance and long-life Stirling cooling type MCT detector, the detection sensitivity reaches ppb level
- Equipped with sophisticated infrared light source, the monitoring path can reach more than 100m
- High stability optical-mechanical hardware system to meet 24H/7Day real-time monitoring
- Meets the requirements for detection and identification of hundreds of industrial compounds (TICs) and chemical warfare agents (CWAs)
- Under complex environmental background, rapid response within 3s, qualitative and quantitative analysis of compounds within 30s
- Optimized algorithms for instrument self-inspection, self-calibration, path interference diagnosis, water vapor compensation, etc.
- Exquisite structural design, simple installation and convenient operation
- Using Fourier transform infrared spectroscopy detection technology, long-distance non-contact sampling
- No consumables, no radioactive sources, no secondary pollution, and extremely low maintenance costs
Technical Indicators
| Monitoring Parameters | |
|---|---|
| Monitoring Type | Hundreds of chemical substances or agents (The factory library contains more than 40 types, expandable up to 520 types) |
| Sensitivity | 0.1~10 ppm |
| Resolution | 4 cm⁻¹ (conventional); 1 cm⁻¹ (highest) |
| Scan Speed | 32 frames/s |
| Monitoring Distance | ≥ 100 m |
| Preheat Time | ≤ 5 min |
| Response Time | ≤ 3 s |
| Recognition Time | ≤ 30 s |
| Operating Hours | 24H/7Day |
| Power Consumption | ≤ 100W / 220V |
| Interface Parameters | |
|---|---|
| Communication | Network port / 5G (optional) |
| Power Supply | AC 220V |
| Physical Parameters | |
|---|---|
| Host | ≤ 560 mm × 370 mm × 260 mm, ≤ 25 kg |
| Light Source | ≤ 420 mm × 250 mm × 270 mm, ≤ 10 kg |
| Electric Control Box | ≤ 400 mm × 280 mm × 200 mm, ≤ 5 kg |
| Environmental Adaptability | |
|---|---|
| Operating Temperature | -10℃ ~ 50℃ |
| Storage Temperature | -30℃ ~ 60℃ |
Application Area
It can be widely used in public environmental monitoring fields such as customs, airports, shopping malls, and chemical industry parks.
