Description
Features
| Parameter name | Performance parameters |
|---|---|
| Detection object | Detection of dangerous chemicals, drugs and precursor chemicals; explosives and precursor chemicals, etc. |
| Factory warehouse quantity | ＞ 3000，Can be expanded according to user needs |
| Adaptive technology | Raman spectroscopic analysis technology, for the liquid, solid and powdery substances in the transparent package, the equipment can complete the detection without touching the sample, and give the specific name and spectrum of the measured substance and other information. |
| Operation method | One-handed operation, one key can complete a test; There are physical buttons for power on/off, detection and return. |
| Detection mode | Quick detection and deep detection two modes |
| Display | 5″ high-definition display, high-sensitivity capacitive touch screen, screen resolution not less than 1920×1080 |
| Human-computer interaction | Multi-touch full Chinese operation interface |
| Spectral range | 200 cm-1~3200 cm-1 |
| Spectral resolution | ≤ 8cm-1 |
| Size | 182 mm ×88 mm ×30mm |
| Weight | 490g with battery |
| Environmental adaptability | Working temperature: -20~+40℃; Storage temperature: -40~+50℃ |
| Working distance | The equipment adopts a pull-type damping probe, and the working distance is continuously adjustable. It can conveniently and accurately detect bottled samples or bagged samples without accessories. |
| Power supply battery | Rechargeable polymer lithium battery, one for one use and one for backup, the working time of a single battery is > 4 hours. A large-capacity battery module can be installed directly, and the working time is ≥ 12 hours. |
| Battery replacement and charging | The battery can be quickly replaced without dismantling the machine or using tools; the battery can be charged independently offline; the adapter can be connected to the mains for charging, it can be charged by the car, and can be charged by a portable mobile power supply; the device can be charged with a power bank while in use |
| Data transmission | Support Wi-Fi, 3G/4G network data transmission. |
| 3G/4G card slot | Support reserved card slots for installing and replacing 4G cards without dismantling the phone. |
| Device location | Support GPS or Beidou for geographic positioning, and send the device location, device status and usage to the cloud background for display. |
| Test result report generation | The device can independently generate a detection report, which includes: item spectral name, attribute, detection time, GPS or Beidou positioning information, QR code, photo, etc. The detection data is automatically saved, and the data storage is not less than 10,000 pieces. |
| SMS push | The device has a SMS push function switch. After it is turned on, the device can automatically send a short message to the bound mobile phone to inform the detection result. The content of the short message includes the detection result, category, matching degree, detection time and location and other information. |
| Data upload and report viewing function | It can automatically exchange data with the cloud background through the wireless network, upload or download relevant information and data; after generating the test report, upload it to the cloud background, and generate a QR code at the same time (the information of the QR code is consistent with the report); it can be scanned by mobile phone QR code, download and view the report; the report can be viewed in the remote background. |
| Self-built library and upload | The device supports users to build their own databases, which can be directly uploaded to the cloud server without a computer and shared with other devices of the same user. |
| Software upgrade | In the state of WiFi or 4G, the operating software can be manually or automatically upgraded without the help of other devices. |
| Database upgrade | Under WiFi or 4G, the database can be upgraded manually or automatically without the use of other devices. |
| Image forensics | The device has a built-in camera, which has the function of taking photos and collecting evidence, and can automatically store photos and add them to the report. The resolution of the camera is not less than 13 million pixels, and the original resolution photos can be exported. |
| Alarm function | When dangerous goods are found, the machine will give prompts in the form of vibration, alarm sound and screen animation. |
Application Area
It can be widely used in anti-drug, customs, public security, security inspection, pharmaceuticals, industrial quality control, fire hazard inspection, mail/express inspection, food safety and other fields.
